| System parameters | ||
|---|---|---|
| System pressure | 210 | bar |
| System flow | 90 | L/min |
| Motor parameters | ||
| Power | 11 | kw |
| Number of revolutions | 1450 | r/min |
| Voltage | 380 | v |
| Frequency | 50 | Hz |
| Fuel tank parameters | ||
| Volume | 400 | L |
| Material | Q235 | |
| Surface treatment | Spray | |
| Feature | |
|---|---|
| 1. | Using low-noise double vane pump with proportional valve control to achieve stepless pressure regulation function |
| 2. | The system uses high and low pressure oil circuits to work together, which greatly reduces the energy consumption of the system and reduces the heat generation of the system |
| 3. | The horizontal installation of the motor is adopted, which effectively saves the installation space |
| Application Industry application | |
|---|---|
| 1. | Powder metallurgy equipment |
| 2. | Forming equipment |
| 3. | Professional equipment |
