| System parameters | ||
|---|---|---|
| System pressure | 210 | bar |
| System flow | 20 | L/min |
| Motor parameters | ||
| Power | 7.5 | kw |
| Number of revolutions | 1450 | r/min |
| Voltage | 380 | v |
| Frequency | 50 | Hz |
| Fuel tank parameters | ||
| Volume | 180 | L |
| Material | Q235 | |
| Surface treatment | Spray | |
| Feature | |
|---|---|
| 1. | The high-pressure plunger pump is used together with the air cooler, which greatly reduces the temperature rise of the system |
| 2. | The system adopts oil circuit design to realize multi-stage pressure output |
| 3. | The vertical installation of the motor is adopted, which effectively saves the installation space |
| Application Industry application | |
|---|---|
| 1. | Ultra high pressure equipment |
| 2. | Waterjet equipment |
| 3. | Professional equipment |
